MCP 24 Fixture Plates

---

400601 - 2.5mm Universal Polishing Fixture (24 position)

400650 - 2.5mm Universal Polishing Fixture (32 position)

400648 - 2.5mm Universal Polishing Fixture (48 position)

150100 - MT/PC (14 position) multimode

150130 - MT/PC (24 position) multimode

150150 - MT/RJ (14 position)

150120 - MT/APC (14 position) singlemode

150122 - MT/APC (24 position) singlemode

200171-1 - APC Ferrule Fixture (12 position) 8.35 degree

200175-1 - APC Ferrule Fixture (12 position) 8.00 degree

200600 - SC/APC (12 position) 8.35 degree

200610 - SC/APC (12 position) 8.00 degree

200620 - SC/APC (22 position) 8.35 degree

200630 - SC/APC (22 position) 8.00 degree

200170-1 - FC/APC (12 position) 8.35 degree

200172-1 - FC/APC (12 position) 8.00 degree

200177-1 - FC/APC (24 position) 8.35 degree conical

200178-1 - FC/APC (24 position) 8.00 degree

400701 - LC/MU (24 position)

400702-B - LC Snap-in (24 position)

400705 - LC Snap-in Duplex/Simplex (48 position)

400772 - LC Snap-in Duplex/Simplex (72 position)

400800-B - LC/APC (24 position) 8.00 degree

400801 - LC/APC (24 position) 8.35 degree

2000001 - 1.8MM V-Groove

2000002 - Snap-In LC (36 Pos)

2000003 - E2000 8.35 Deg ferrule fixture Huber & Suhner

2000004 - SMA.125" 905 type

2000005 - Custom 32 pos uni

2000007 - 8 deg v-groove array (wafer) 14 pos

2000008 - APC Ferrule Fixture 6.35 deg 12 Pos

2000009 - Wafer

20000010 - Single Step Fixture

20000011 - 14 pos 16 Fiber 8 deg MTP plate

20000012 - 36 Pos Titanium Fixture

20000016 - 14 Pos 16 Fiber MTP Plate

20000017 - E2000 8.35 Deg ferrule fixture diamond usa (R& M)

20000018 - LC APC (8.00)

20000023 - MCP-24 2mm LEVEL JIG

20000024 - 6 DEG VGROOVE MCP24

20000025 - 10 DEG VGROOVE MCP24

20000026 - .150 LEVEL JIG MCP24

20000027 - 29504 24 pos ( same as 46 plate for MCP12)

20000029 - Custom 24 Pos

20000030 - Custom 32 pos uni

20000031 - 24 POS CUSTOM SLIDER FOR UNI-24

20000035 - MCP24 0 Deg V-Groove

20000036 - Ferrule Leveling Jig

20000039 - MCP24 0 Deg V-Groove (Short Ferrule)

20000040 - Ferrule Leveling Jig

20000042 - 1mm Leveling Jig

20000043 - MCP24 2.5mm 0 Deg V-Groove

20000044 - 2.5mm Level Jig

20000045 - 1 Piece Escon Fixture Snap-In

NMT400615 - ST/PC amp overmolded connector design (24 pos)

20000052 - 24 position Fixture Plate (illuminating plate)

20000053 - slider for 20000052 (illuminating plate)

20000054 - APC Polish Fixture for PHD termini (18 pos) for MCP24

20000055 - level jig for 0 deg v-groove.0040'  for p/n (20000041)

20000056 - 400601 base plate (new plate w/o p/n to be built)

20000057 - 29504/5 s;ider fixter /same as 46 for MCP12

20000061 - MCP24 Plastic Optical Fiber-32 pos

20000062 - MCP24 Radiall Luxcis Termini

20000063 - MCP24 Plastic Optical Fiber (POF)

20000064 - MCP24 Plastic Optical Fiber (POF)

20000068 - MCP24 Bare Fiber fixture

20000069 - Metal Connector

20000070 - Radial Luxis Termini MCP12 (12 pos) slider

20000071 - SC/APC  8 deg

20000077 - lc/mu 400701 with lower ferrule nipple

20000084 - lc/apc ferrule fixture (custom)

20000089 - 8.35 apc fixture for mu/apc MCP24

200173-1 - 2.5 apc ferrule fixture 11 degrees

20000094 - Dual v-groove fixture every other flat ever other 4.5 degrees

20000098 - TFOCA II plate 1/4 inch bottom plate longer ferrule

20000099 - 0 degree vgroove (2mm - 1.25mm ferrule)

20000101 - regular 14 pos very shallow groove small connector

20000102 - TFOCAII plate 3/16 thickness for 6.30mm ferrule

400801 - 8.35 LC/APC polishing fixture

400705 - 48 pos lc snap in plate f

20000101 - regular 14 pos very shallow groove small connector

20000114 - ARINC 1.25 APC FERRULE FIXTURE  MCP24

20000115 - APC ferrule fixture Lancer

20000116 - APC ferrule fixture Lancer

200700 - SC/APC custom 24 pos. plate

20000122 - Leveling jig

20000126 - Avago HFBR connectors

20000127 - sllider

21111128 - T-Foca II 24 pos rotary fixture 2.5mm ferrule

20000129 - 0'degree v-groove same as 41 but 18 pos instead of 14 pos
