MCP 12 Fixture Plates

Nanometer Technologies manufactures polishing fixture plates for all major fiber optic connectors. We also manufacture custom fixture plates to meet your customers needs.

Get A Quote

MCP 12 Fixture Plates

 600601 - 2.5mm Universal Polishing Fixture

200160-1 - FC/APC (8 position) 8.35 deg

200161-1 - FC/APC (8 position) 8.00 deg

200450 - 8 degree V-Groove (8 position)

200700 - SC/APC (6 position) 8.35 degree

200605 - SC/APC (6 position) 8.00 degree

150200 - MT/PC (6 position) Multimode

150201 - MT/PC (12 position) Multimode

150250 - MT/RJ (6 position)

150220 - MT/APC (6 position) 8.00 degree

600602 - LC/MU (12 position)

600702 - LC Snap-in (24 position)

600705 - LC/APC (12 position) 8.35 degree

20000013-SL - MC5 Termini (600602 + Rifocs holder)

20000014 - 29504/4  no counter bore

20000015 - 29504/5 .094 counter bore/ 1.6mm ferrule

20000019 - 10 POS 6 DEG V GROOVE (FOR 6.5mm FERRULE)

20000020 - MCP-12 LEVEL JIG (.05" PROTRUSION)

20000021 - 10 POS 0 DEG V GROOVE (FOR 6.5mm length FERRULE)

20000022 - 16 POS 0 DEG MULTI-WAFER PLATE (4 SIZES)

20000032 - 10 POS 2 DEG V GROOVE

20000033 - MCP-12 SMA 905 .125"

20000034 - 1.3MM 0 Degree V-Groove for Titanium Ferrule

20000037 - MCP12 Mill. Conn. 29504/10

20000038 - 12 Pos. Quick Plate

20000046 - MIL29504 (Socket termini) 1.6 mm

20000047 - MIL29504-15 Packard Hughes Delphi-2mm fixture

20000048 - MIL29504-15 Packard Hughes Delphi-slider

20000049 - MIL29504-5 slider for glenair termini #181-002

20000050 - Glenair 29504-5 pin termini #181-002 1.6 mm ferr

20000051 - 600602 LC/MU,   Rifocs MC5 Termini

20000058 - 12 pos IPC plate (600601 uni base)

20000059 - mcp12 10 pos custom fiber mount

20000060 - level jig for fiber mount connector

20000065 - E2000 (Diamond) 8.35deg  for mcp12  10 pos

20000066 - slider for nmt-20000065 E2000 8.35deg

20000067 - MCP12 Plastic Optical Fiber (POF)

20000072 - MCP12 16 position St Plate

20000075 - lc/mu 12 position 600602 1.25mm mcp12

20000076 - 0'vgroove mcp12  29504/15

20000076LJ - 3.429mm leveling jig for 29504/15

20000085 - custom pof custom connector

20000086 - custom pof custom connector

20000086LJ - leveling jig

20000088 - T-Foca 18 pos rotary fixture 2.5mm ferrule

20000088SL - T-foca18 pos rotary slider 2.5

600705 - 24 pos LC snap in duplex/simplex for MCP12

20000110 - .5 degree v groove for SMA

20000113 - levleing jig for mcp12 v groove

20000120 - 3.1mm sma special type S.i. tech (MCP12)

200458 - cuatom v-groove

200000124 - ARINC 1.25 APC FERRULE FIXTURE  MCP12
