Smart epoxy fiber optic curing oven - Smart Oven

    Cure 24 Connectors at a time.


    The Smart Curing Oven was specifically designed to work with MT style connectors, but also works great with many other styles of connectors.
    The horizontal positioned heating block gives users the ability to cure custom style connectors with ease. With a built-in alarm system, you'll avoid over-curing your connectors.
    The 4.3” touch screen PID process controller enables repeatable performance with accurate temperature control. With the ability to store up to 30 temperature profiles and epoxy types.

    Telecommunications equipment epoxy curing oven Fiber Optic Curing Ovens.


    Get a Quote

    Cure 24 connectors at a time

    Cure many types of connectors

    Cure 24 connectors at a time

    Fiber Optic Curing Ovens - Cure 24 connectors at a time

     The Heating Block will hold 24 MT style connectors.

    Precise Control

    Cure many types of connectors

    Cure 24 connectors at a time

    Fiber Optic Curing Ovens

    7 inch touch screen with 30 recipes storing all major Mfg epoxy cure times/temps.  ensure accurate repeatable performance.  Ramp/Soak function for Mil Spec. applications

    Cure many types of connectors

    Cure many types of connectors

    Cure many types of connectors

     The MT-24 works with most 2.5 & 1.25 Ferrules and custom applications

    Get a Quote

    Smart Curing Oven Quote Form

    This site is protected by reCAPTCHA and the Google Privacy Policy and Terms of Service apply.

    Better yet, see us in person!

    We love our customers, so feel free to visit during normal business hours.

    Nanometer Technologies Inc

    2985 theatre Dr #3, Paso Robles, CA 93446, US

    (805) 226-7332

    Cure 24 Connectors at a time.


    The Smart Curing Oven was specifically designed to work with MT style connectors, but also works great with many other styles of connectors.
    The horizontal positioned heating block gives users the ability to cure custom style connectors with ease. With a built-in alarm system, you'll avoid over-curing your connectors.
    The 4.3” touch screen PID process controller enables repeatable performance with accurate temperature control. With the ability to store up to 30 temperature profiles and epoxy types.

    Telecommunications equipment epoxy curing oven Fiber Optic Curing Ovens.


    Specifications:

    Resolution: 0.25deg C

    Accuracy: +/- 2.5 deg C @ 150deg C , +/- 2 deg C @ 25-120 ( thermocouple accuracy )

    Max Temperature: 150 deg C

    Stability: (lid closed) +/-0.75 deg C

    Heating: 12 deg./Min.

    Cooling: 1.5 deg / min.

    Settling time: 3 minutes

    Capacity: 24 connectors (variable depends on heater block)

    Weight: 5 lbs.

    Power 120vac or 240 vac 3 amps

    Width: 13.5” 343mm, Height 5” 127mm, depth 9.3” 236mm

    Ramp/Soak Specs:

    10 steps per profile

    Program time and temps

    Save up to 25 profiles

    Save names per profile

    Linear ramping to temp.

    Over shoot +/- 5 %

    160degC thermal shutdown protection

    Buzzer on/off switch

    Pre-set Oven Profiles list:

    LMCO ramp soak Mil Spec.

    353ND 150c 1min

    353nd 120c 5 min

    353nd 100 10min

    353nd 80c 30min

    F112 90c 15min

    F123 100c 5min

    3577 150c 30min

    3677 120c 60min

    AB9123 100C 5 Min

    AB9123 120C 2MIN

    AB9123 150C 1MIN

    1min 100c
